2 cylinder diesel generator KS 13-1DEW 1/3 ATSR

Voltage
230/400
Max power (400V), kVA 11.25
Nominal power (400V), kVA 10.63
Max/Nominal power (230V), kW 8.1/7.7
Max/Nominal power (400V), kVA 11.25/10.63
Frequency, Hz 50
Vool (max.) 230/400 V, A 36.96/16.26
Outlets 1 x Schuko 230 V
1 x CEE 230 V 32 A
1 x CEE 400 V 16 A
1 x CEE 400 V 32 A
Avg. working time (power 50%), h*** 13.6
LED display Voltage, frequency, working hours
Noise level Lpa (7m)/Lwa, dB 73/98
Power output DC, V/А 12/8.3
Engine type Diesel powered V-twin water-cooled two-cylinder, four-stroke
Engine model KS 820HD
Engine power, hp/kW 18.0/13.24
Preheater +
Fuel tank volume, l 30
Crank case volume, L 3.3
Coolant volume, l 3.5
Engine cylinder volume, cm3 794
Power output controller Intelligent voltage stabilization system AVR
Engine start Electric
Accumulator, A·h 45
Output for ATS +
Protection class IP23M
Net dimensions (LxWxH), mm 1050x640x700
Gross dimensions (LxWxH), mm 1100x680x820
Net weight, kg 210
Gross weight, kg 240
EAN code 4260405363162

*** Fuel consumption depends on many factors, such as load, fuel quality, season, altitude, technical condition of the generator.

Assembled in PRC.

DELIVERY 6 MONTHS

SKU KS141DEATSR-1 Categories ,



HIGH-PERFORMANCE TWO-CYLINDER ENGINE

High-performance optimally balanced V-twin water-cooled two-cylinders four-stroke engine (18 hp), which ensures reduced vibration of the generator during operation and it has the enlarged motor resource.

VTS SYSTEM

Universal generators 2 in 1 have a unique VTS (voltage Transfer Switch) phase switching system, which allows using a single generator both in single-phase mode (230V) and in three-phase mode (400V) with almost no loss of power. Each mode has its own circuit breaker. There is no need to use two separate generators.

MULTIFUNCTION LED DISPLAY MULTIFUNCTION LED DISPLAY

Modern multifunction LED display shows frequency, voltage and operating hours of the generator. Displayed information makes it easy to determine the voltage generated by the device.

ATS OUTPUT (ATS 4/63HD)

The generator is suitable for connecting the ATS (Automatic Transfer Switch) system. The ATS (Automatic Transfer Switch) unit automatically starts the generator and transfers load to it when the main power supply is disconnected and automatically stops the generator when the central power supply is restored.

PREHEATER FUNCTION

All Heavy Duty series generators are equipped with a preheat function, which allows you to easily start a generator in winter.

STEEL TANK

“Könner & Söhnen” generators are equipped with an enlarged steel fuel tank, which extends the generator’s operating time without refueling. The fuel level indicator is located on the tank for ease of use.

***Fuel consumption depends on many factors: load, fuel quality, season, altitude and generator technical condition.
